Durable Fish Finder Protection for Extreme Conditions

The Fish Armor series of live imaging enclosed platforms are designed for the modern angler. Whether you're ice fishing, exploring remote areas, or fishing from a dock, our protective shuttles are built for all weather conditions.

FISH ARMOR PRODUCT LINEUP



Fish Armor Pro Lite Live Imaging Shuttle

Fish Armor
Pro Lite Live Imaging Shuttle

The all new Fish Armor Pro Lite. Roto Molded for extreme conditions. Smaller profile for those fisherman looking to minimize space constraints for their Garmin Live Scope, Lowrance Active Target, or Humminbird Mega Live. Integrated black box protection. Coming in at 4.8 lbs, the Pro Lite is one of the lightest most versatile shuttles available. Molded integrated feet allow for rock solid mounting on your boat, ATV or wherever you want to mount our docking plate. Fast, simple rigging with our aluminum black box and battery tray including simple access to your battery with only two thumb screws. Comes with 4 pre-wired switches and USB/C port – plug and play rigging. Pictured with optional accessories. Will fit up to Amped Outdoors 52ah and Norsk 50ah batteries. Will not fit the Amped Outdoors 30ah tall battery.

MADE IN THE USA

Fish Armor Pro Extreme Live Imaging Shuttle

Fish Armor
Pro Extreme Live Imaging Shuttle

The all-new Fish Armor Pro Extreme. Roto-molded for extreme conditions, providing lightweight, full protection for your forward-facing sonar unit and all components for your Garmin Livescope, Lowrance Active Target or Humminbird Mega Live. Flush mounting screen availability sheds weight and offers maximum protection (available for most screen types). Positive locking marine-grade aluminum door doubles as your sun shield with our tension adjustable friction hinge design. Developed by fishermen for fishermen. Weighing only 6.8 lbs, it ensures easy transport. Molded integrated feet allow for rock-solid mounting on your boat, ATV, or wherever you want to mount our docking plate. Add a myriad of accessories such as our foam-lined transducer protector, LEDs, charge port, or even the backpack system. Comes with 4 pre-wired switches and USB/C port—plug-and-play rigging. Height – 22″ Width – 14.875 Depth 8.75″. Pictured with optional accessories – check them out under the accessories tab. Will fit up to Amped Outdoors 52ah and Norsk 50ah. Patent Pending.

MADE IN THE USA



Fish Armor Shuttle v2024

Fish Armor
Original Brand Shuttle v2024

The 2024 edition introduces a fully adjustable shelf with 3 positions to accommodate ALL 9″ screens, ALL 10″ screens and even Garmin 8612, 1243 or 126 UHD models. (Note: Humminbird and Lowrance 12″ models will NOT fit in this shuttle.) This model is crafted with pre-drilled mounting holes ready for weather-proof LED add-ons, SAE Charge port, and Clam Pucks – offering a plethora of customization options. All these components, along with the necessary hardware, are available in our accessories tab. Simple, easy installation. Equipped with a collection of innovative protective elements tailored for the advanced angler. USB-A and USB-C ports ensure broad electronic device compatibility. Rugged switches, optimized for marine environments, deliver unmatched control. Patent Pending. Includes: 4 pre-wired switches, USB port, Ball Bungees, and the Fish Armor stencil kit installed. Exterior dimensions: Width: 14.75” Depth: 9″ Height: 16” Battery and black box storage: Width: 14.25” Depth: 8.50” Height: 7.625” (subtract 1.5” for 10 and 12 inch displays) Empty Shuttle Weight: 8.5lbs Screen size will determine shelf height

MADE IN THE USA

Fish Armor Live Imaging Pro Pole

Fish Armor
Live Imaging Pro Pole

The all new Fish Armor Pro Pole. Transducer cord through pole design allows not only protection for your cord, but simply makes it the most manageable cord system available for your Garmin Livescope, Lowrance Active Target or Humminbird Mega Live transducer. Rigid aluminum extending pole in lengths of 36″, 60″ and 80″ – 100% machined compenents. Comes with Ice Tri-Pod, handle and Transducer connection hardware for Garmin, Lowrance or Humminbird. Patent Pending. Pole length ranges: 36” = 23″to 42″. 60” = 30″ to 66″. 80” = 37″ to 86″.

MADE IN THE USA

Premium Features for Advanced Anglers

Roto Molded for extreme durability,
The all new Fish Armor Extreme and Pro Lite models offer the protection you need for your
Garmin, Humminbird, and Lowrance fish finders.



Customizable Platform

Customizable Platform

Add rod holders, lights, and more to create your perfect fishing setup.

Marine-Grade Smart Control

Marine-Grade Smart Control

Recessed switch panel protection. Power screen, computer, lights, etc. Optional SAE charge port & HDMI port.

Cord Through Pro Pole

Cord Through Pro Pole

Protect your transducer cord and get rid of the clips or velcro holding your ducer cord. 100% machined for the smoothest rotation.

Quick Access Design

Quick Access Design

Rubber positive latch holds marine grade aluminum door fast. Keep your screen protected.

Durable Hinge System

Durable Hinge System

Friction hinges allow door to be used as a sun sheild with unlimited settings.

Convenient Transportation

Convenient Transportation

Optional backpack straps for easy carrying.

Docking Plate

Docking Plate

Mount both the Extreme and Lite versions on our alluminum docking plate wherever you see fit; UTV, Boat, Ice Machine.

Pro Lite

Pro Lite

Integrated black box protection and available quick lock pole holder.

Pro Lite Battery/Computer Tray

Pro Lite Battery/Computer Tray

Simple rigging with removable tray with two thumb screws.

Maximum Transducer Protection

Maximum Transducer Protection

Foam layer designed to guard against potential damage.

Pro Extreme Pole Holder

Pro Extreme Pole Holder

Opt to go without transducer protector and keep pole on top of Pro Extreme.

Pro Lite Pole Holder

Pro Lite Pole Holder

Add pole holder for your Pro Lite.

Shelf-Gimbal Mount Option

Shelf-Gimbal Mount Option

Use the shelf mount option for screen types not conducive to flush mounting.

INSTRUCTIONAL VIDEOS

Pole Video

POLE

PRO LITE VIDEO

PRO LITE

Pro Extreme Video

PRO EXTREME

Pro Extreme Video

PRO EXTEME ACCESSORIES

Pro Extreme, Pro Lite and Pro Pole Assembly Guide

Note: Do NOT use power tools during the assembly process. Hand tools only. Snug all screws but do not over tighten.

Tools required:
Back Panel Extreme:  1/8" Allen
Hinge Tensioner:  2.5mm Allen
Switch Panel, LED's & SAE - Extreme & Lite:  Phillips
Pole Holder - Extreme & Lite:  5/32" Allen & 7/16" socket or wrench
Docking Plate Cleats: 3/16" Allen
Docking Plate Peg on Extreme & Lite: 1/8" Allen

Drill Bit Sizes:
Pole Holder for Extreme & Lite:  1/4"
LED Lights:  1/4" for wire. 1/8" for mounting screws.
Docking Plate Peg: 7/32"

Bolt Photos

Pro Pole Transducer Bolt/Washers/Nut Configuration by Manufacturer

v2024 Aluminum Shuttle Assembly Guide

2024 INSTRUCTION VIDEOS

FISH ARMOR ASSEMBLY VIDEOS

FISH ARMOR ASSEMBLY

FISH ARMOR DISASSEMBLE Video

FISH ARMOR DISASSEMBLE

Fish Armor Package Video

FISH ARMOR PACKAGE

Step 1

STEP 1

Remove the center shelf by taking out the 4 button head screws (2 per side) using the provided 3mm allen wrench.

Pro tip: Shelf removal and installations are the easiest when the shuttle is lying on its side.

Step 2

STEP 2

Set your shelf height by moving the locking ball stud on the front of the shelf. The bottom position is designed for 9" and smaller screens. The middle position accommodates ALL 10" models from brands like Garmin, Humminbird, and Lowrance. Opt for the top position if you have Garmin 12" models such as 8612, 1243, and 126 UHD. When remounting the shelf, ensure you align the button head screws with your chosen ball stud location. Otherwise, your lower door will not close.

Note: Lowrance and Humminbird 12" screens will NOT fit in this shuttle. Pro Tip: When going on long trips, use the locking pins to secure your doors.

Step 3

STEP 3

Remove the internal computer/battery tray. Take out the 2 button head screws on the back of the shuttle using the provided 3mm allen wrench.

Pro Tip: This tray can be removed with your computer and battery attached, allowing for an easy transition to your boat.

Step 4

STEP 4

Install the velcro battery straps as pictured. Utilize the slots that best fit your battery.



Pro Tip: As an alternative to the included velcro straps, you can customize your battery’s location. Consider purchasing a high-quality sticky back velcro and adhere it to the bottom of your battery and the top of the battery tray. Some of our pro-staff have relocated their battery to the far left, creating more storage space. Both systems are effective!

Step 5

STEP 5

Install the computer (black box). Use the provided 1.25" philips head stainless bolts and nylock nuts. IMPORTANT: Bolts must pass from the back of the computer tray toward the front. Refer to the picture for clarity.



Pro Tip: You have two options for handling cables. Either run your cables and connect them to the computer before reinstalling the bracket, or install first and utilize the back access panel for all connections. Both methods are effective!

Step 6 Photo

STEP 6

Reinstall the computer/battery tray into the shuttle. Simply reverse the process detailed in Step #2.

Step 7

STEP 7

Install the Gimbal bracket on the center shelf using the provided 3/4" bolts and nylock nuts.

Pro Tip: By reversing your gimbal bracket, you can gain additional room in front of your screen, ensuring more shade from the sun when fishing outdoors. This technique is particularly effective for larger 10″ screens, but is beneficial for all units. If you’re using a 9″ or smaller screen and decide to upgrade to a 10″, remember that the center shelf height is adjustable to accommodate these larger screens.

Step 8

STEP 8

Reinstall the shelf by reversing the instructions in Step #1. Do NOT overtighten the screws, as this can damage your carbon fiber wrap.

Pro Tip: Lay the shuttle on its side to better align holes by looking down on them.

Step 9

STEP 9

Adhere to the wiring instructions and manufacturer's guidelines for all cable plugs.

Pro Tip: When installing the transducer cord, there’s no need to wrap the entire length around the handle. Only wrap the amount you need for your specific setup, and store the excess inside the box, behind your screen.

Step 10

STEP 10

Go Fishing!

2023 ASSEMBLY INSTRUCTIONS

Note: Do NOT use power tools during the assembly process. Hand tools only. Snug all screws but do not over tighten.

Tools required:

Philips head screwdriver
10mm wrench or socket
12mm wrench or deep well socket
3mm Allen Wrench provided The Fish Armor shuttle was designed for ease of assembly.

Follow these simple instructions and be on your way.

Note: Do NOT use power tools during the assembly process. Hand tools only. Snug all screws but do not over tighten.

Tools required: Philips head screwdriver 10mm" wrench or socket 3mm Allen Wrench provided



The Fish Armor shuttle was designed for ease of assembly. Follow these simple instructions and be on your way.



2023 Step 1

STEP 1

Remove center shelf by removing 6 button head screws (3 per side) with provided 3mm allen wrench. Pro Tip: Shelf removal and installations are easiest when shuttle is laying on its side.

2023 Step 2

STEP 2

Remove internal computer/battery tray. Remove 2 button head screws on back of shuttle with provided 3mm allen wrench.



Pro Tip: This tray can be removed leaving your computer and battery attached for an easy transition to your boat.

2023 Step 3

STEP 3

Install velcro battery straps as pictured - use the slots that fit your battery.

Pro Tip: As an alternative to using the included velcro straps, you can customize your battery's location. Purchase a high quality sticky back velcro and adhering to the bottom of your battery and top of battery tray. Some of our pro-staff have moved their battery to the far left allowing for more storage. Either system works great!

2023 Step 4

STEP 4

Install computer (black box). Use provided 1.25" philips head stainless bolts and nylock nuts. IMPORTANT: Bolts must pass from the back of the computer tray toward the front. See picture.

Pro Tip: You can either run your cables and plug into the computer prior to re-installation of bracket, or you can install now and use the back access panel for all plugs. Both ways work great.

2023 Step 5

STEP 5

Reinstall computer/battery tray into the shuttle by reversing step #2.

2023 Step 5b

STEP 5b

Install Gimbal bracket on center shelf. 3/4" bolts and nylock nuts provided.

Pro Tip: By reversing your gimbal bracket, you will get more room in the front of your screen and more shade from the sun when fishing outside. This works best on larger 10" screens but is a good idea for all units. If you are running 9" or smaller screen and upgrade to a 10" know that the center shelf height is adjustable to accommodate the larger screens.



2023 Step 6

STEP 6

Reinstall shelf reversing step #1.

Do NOT overtighten the screws or damage may occur to your carbon fiber wrap.

Pro Tip: Place shuttle on its side and align holes viewing down.

2023 Step 7

STEP 7

Follow wiring instructions and manufacturers instructions on all cable plugs.

Pro Tip: When installing the transducer cord, there is no reason to have all of the cord wrapped on the handle. Only wrap what you need for your situation and store the remainder inside the box behind your screen.

2023 ASSEMBLY INSTRUCTIONS

Accessory Installation Note:

Do NOT use power tools during the assembly process. Hand tools only. Snug all screws but do not over tighten.

Tools required:

Philips head screwdriver, 10mm wrench or socket, 12mm wrench or deep well socket, 3mm Allen Wrench provided

The Fish Armor shuttle was designed for ease of assembly. Follow these simple instructions and be on your way.

Accessories Installation - Clam Puck

Clam Puck

Effortless Clam Puck Installation Guide

Step#1: Locate each set of two holes on the right side of the shuttle as you face it (refer to the picture). Punch the holes open and install your clam puck using the provided screws and nuts.

Accessories Installation - Charge Port

Charge Port

Installling the SAE Charge Port on Your Shuttle

Step 1: Locate your SAE CUTOUT on the left side of your shuttle. Cut the wrap and remove the cutout plug. Initiating the removal might require pressing the edge of the hole with a hard object. Simply bend it back and fourth until it's out.



2023 Assembly Step 2b

Charger Port Part 2

Install with 2 flat head screws and nyclock nuts.

2023 Assembly Lights

Lights

Guidelines for Installing LED Lights on Your Shuttle

Step#1: Identify each set of 3 holes. One set is situated on the upper right of the shuttle, white the other is located on the left towards the back. Open all three holes and install the lights using the provided hardware. Follow the wiring instructions provided.

Lifetime Warranty The Fish Armor™ Protective Case is warranted for the lifetime of the product against defects in material and workmanship. This warranty does not cover transportation damage, misuse, accidental incidents, or similar incidents. Any attempt to interfere with the protective Case makes this warranty null and void. This warranty gives you specific legal rights and you may have other rights, which vary from state to state. This product is intended for household use only, not for commercial use. This warranty does not cover commercial use.

One Year Limited Warranty The Fish Armor™ Protective Case electrical components or any additional add-on components are warranted for one year from the date of original purchase against defects in material and workmanship. This warranty does not cover transportation damage, misuse, accidental incidents, or similar incidents. Any attempt to interfere with the operation of any electrical components or any additional add-on components makes this warranty null and void. This warranty gives you specific legal rights and you may have other rights, which vary from state to state. This product is intended for household use only, not for commercial use. This warranty does not cover commercial use.
